Newly developed lockstitch machine provides upgraded quality and a comfortable environment that increase Efficiency.
The thread take-up mechanism, feed mechanism, thread path and hook have been further improved to enhance responsiveness to material changes and to ensure consistent stitch quality.
The sewing mechanism demonstrates outstanding responsiveness to materials being sewn.
The thread take-up mechanism, feed mechanism, thread path and hook have been further improved to enhance responsiveness to material changes and to ensure consistent stitch quality.
Higher lift to presser foot
The ample lift of the presser foot makes it easier to set or remove materials or to sew overlapping sections.
The arm configuration is designed to provide a larger sewing space.
Permits easier cloth handling while sewing.
The Feed and Lubricating mechanisms have improved Durability.
The durability of the machine frame and components has been improved. This will result in long-range economy.
Machine Specifications
- Application: For medium weight materials
- Max Sewing Speed: 5,500 stitches per minute
- Max Stitch Length: 4mm
- Needle bar stroke: 30.7mm
- Lift of the presser foot by hand: 5.5mm
- Lift of the presser foot by knee: 13mm
- Needle (at the time of delivery): DBX1 (#14) – For JE: 134 (Nm75)
- Hook: Automatic-lubricating full-rotary hook
- Lubrication: Automatic
- Lubricating oil: Juki New Defrix Oil No. 1
Warranty : 1 year
